The RC-CC2652PA module is designed based on CC2652R and CC2592 of Texas Instruments.

The CC2652R device is a multiprotocol wireless 2.4GHz MCU targeting Thread, Zigbee, Bluetooth 5
low energy, IEEE 802.15.4g, IPv6-enabled smart object (6LoWPAN), Wi-SUN, and proprietary systems.
The CC2592 device is a cost effective and high performance RF front end low-power and low-voltage
2.4- Ghz wireless applications. To increase the link budget, the CC2592 device provides a power
.
amplifier for increased output power and an LNA with a low-noise figure for improved receiver sensitivity.
The RC-CC2652PA module is designed based on CC2652R and CC2592 of Texas Instruments.

Functional Block

Mechanical Dimension

Download Datasheet
